YJD190
Contact UsProduct specifications
Image Sensor
640 * 480 pixels
Light Source
LED White light
Reading Angle
Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°
Input Voltage
5 VDC (+/- 10%)/500mA
Cordless mode
2.4G & Bluetooth
Features
![](https://www.lonvillscan.com/upload/files/article/20240321/17110074562916823.png)
1D
![](https://www.lonvillscan.com/upload/files/article/20240321/17110074625536317.png)
2D
![](https://www.lonvillscan.com/upload/files/article/20240321/17110074654028784.png)
CMOS
![](https://www.lonvillscan.com/upload/files/article/20240321/17110074665961226.png)
IP
![](https://www.lonvillscan.com/upload/files/article/20240321/17110074772150501.png)
2.4G Wireless
![](https://www.lonvillscan.com/upload/files/article/20240321/17110074857226299.png)
Bluetooth
Application Scenarios
![](https://www.lonvillscan.com/upload/files/article/20240321/17110075239433437.png)
Logistics Warehouse
![](https://www.lonvillscan.com/upload/files/article/20240321/17110075277553717.png)
Manufacturing
![](https://www.lonvillscan.com/upload/files/article/20240321/17110075335431908.png)
Public sector
![](https://www.lonvillscan.com/upload/files/article/20240321/17110075371945598.png)
Retail
Features
Specifications
PRODUCT FEATURES
• Robust Construction
YJD190 is built to withstand harsh working conditions with its two-color mold ABS+TPU design, ensuring shock-proof and anti-drop capabilities.
• One Key Pairing
The one-key pairing function can quickly conect the scanner and the wireless base.
• Advanced Decoding Algorithm
Equipped with a patented decoding algorithm, it efficiently reads damaged, stained, wrinkled, and color barcodes with speed and accuracy.
• Versatile Compatibility
Supports various keyboard languages, requires no drivers, and offers plug-and-play functionality for effortless setup.
• User-Friendly Features
Features one-key pairing and one-key search functions for simple operation, making it easy for users to get started quickly.
PRODUCT ATTRIBUTES
Light Source | LED White light |
Image sensor | 640*480 pixels |
Resolution(maximum) | 0.102mm / 4mils |
Print contrast ratio(minimum) | ≥20% |
Reading Angle | Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60° |
Decoding Capability | 1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded. |
2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code | |
Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417. | |
Reading Indicators | LED light&Buzzer(adjustable tone and volume) |
Typical depth of Field | 3.34mil CODE 128 10mm—60mm 10mil PDF417 5mm—190mm |
Current | Working current(Standard): < 270 mA |
Input Voltage | 5 VDC (+/- 10%)/500mA |
ESD protection(Air discharge) | 8 kV |
Drop resistance | Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface. |
Particulate and water sealing | IP52 |
Temperature | Working: 0 to 40 °C |
Humidity(non-condensing) | 5 - 95% |
Ambient light | Indoor: 0 to 6,000 lux, |
Cordless mode | 2.4G & Bluetooth |
Transmission distance | 2.4G: 100 meters; Bluetooth: 50m (basic on open space) |
Communication mode | Wireless real-time transmission/wired transmission/storage mode |
Battery capacity | 2000mAh |
Continuous working time | >12H |
Charging time | 4~5H |
Warranty | 2 years |
